Design · Sauna heaters
EOS Mythos series
Top class in design and quality.
- Power
- 2–15 kW
Power
Model
Version
Delivery with certification and an approved project. Heaters from the Design and Professional lines are supplied with certification and submission of the project, so that we can approve delivery and installation. Classic and Standard heaters can be ordered by anyone.
Send project for approval
We send the price, availability and delivery time in reply to your enquiry, usually the same or the next working day.
Data is being transferred from the EOS catalogue.
For technical data and documents, see the original page or send us an enquiry.
| Electrical connection | 400 V 3N ~ 50/60 Hz |
|---|---|
| Device dimensions H/W/D (cm) | 84 / 42 / 37 (EOS Mythos S35) 84 / 50 / 37 (EOS Mythos S45) |
| For Cabin volume (7,5 / 9,0 / 12,0 / 15,0 kW) | 8 - 12 m³ / 10 - 14 m³ / 14 - 18 m³ / 18 - 25 m³ |
| Minimum size Be- and exhaust (7,5 / 9,0 / 12,0 / 15,0 kW) | 35 x 5 cm / 35 x 6 cm / 35 x 7 cm / 35 x 9 cm |
| Fuse Controller | 3 x 16 A |
| Weight without stones and packaging | 34 kg (EOS Mythos S35) 40 kg (EOS Mythos S45) |
| Stone quantity | 35 kg (EOS Mythos S35) 45 kg (EOS Mythos S45) |
| Snagasschaltgeträt required (7,5 - 9 kW / 12 - 15 kW) | Ne / PEB 10 |
| Electrical connection | 230 V 1N ~ 50 Hz |
| Vaporizer Power | 2,0 kW / 3,0 kW |
| Vaporizer Dimensions H/W/D, in cm | 84 / 8 / 37 |
| Vaporizer Volumen | 10 l |
| Verbindung Controller - Vaporizer | 5 x 1,5 mm² |
| Model | Version | Power | EOS item no. | |
|---|---|---|---|---|
| EOS Mythos S35 | anthracite | 7,5 kW | 945488 | |
| EOS Mythos S35 | anthracite | 9,0 kW | 945489 | |
| EOS Mythos S35 | crna | 7,5 kW | 946066 | |
| EOS Mythos S35 | crna | 9,0 kW | 946067 | |
| EOS Mythos S35 | bela | 7,5 kW | 945988 | |
| EOS Mythos S35 | bela | 9,0 kW | 945989 | |
| EOS Mythos S35 | Water Reflection | 7,5 kW | 949591 | |
| EOS Mythos S35 | Water Reflection | 9,0 kW | 949592 | |
| EOS Mythos S35 | Dark Bronze | 7,5 kW | 949408 | |
| EOS Mythos S35 | Dark Bronze | 9,0 kW | 949409 | |
| EOS Mythos S45 | anthracite | 12,0 kW | 945490 | |
| EOS Mythos S45 | anthracite | 15,0 kW | 945491 | |
| EOS Mythos S45 | crna | 12,0 kW | 946068 | |
| EOS Mythos S45 | crna | 15,0 kW | 946069 | |
| EOS Mythos S45 | bela | 12,0 kW | 945991 | |
| EOS Mythos S45 | bela | 15,0 kW | 945992 | |
| EOS Mythos S45 | Water Reflection | 12,0 kW | 949589 | |
| EOS Mythos S45 | Water Reflection | 15,0 kW | 949590 | |
| EOS Mythos S45 | Dark Bronze | 12,0 kW | 949406 | |
| EOS Mythos S45 | Dark Bronze | 15,0 kW | 949407 | |
| EOS Mythos Vapor | Links, 3 kW anthracite | 3,0 kW | 945572 | |
| EOS Mythos Vapor | Rechts, 3 kW anthracite | 3,0 kW | 945493 | |
| EOS Mythos Vapor | Links + rechts, je 3 kW anthracite | 6,0 kW | 946250 | |
| EOS Mythos Vapor | Links, 2 kW anthracite | 2,0 kW | 945571 | |
| EOS Mythos Vapor | Rechts, 2 kW anthracite | 2,0 kW | 945492 | |
| EOS Mythos Vapor | Links + rechts, je 2 kW anthracite | 4,0 kW | 946253 | |
| EOS Mythos Vapor | Links, 3 kW crna | 3,0 kW | 945902 | |
| EOS Mythos Vapor | Rechts, 3 kW crna | 3,0 kW | 945906 | |
| EOS Mythos Vapor | Links + rechts, je 3 kW crna | 6,0 kW | 946262 | |
| EOS Mythos Vapor | Links, 2 kW crna | 2,0 kW | 945901 | |
| EOS Mythos Vapor | Rechts, 2 kW crna | 2,0 kW | 945905 | |
| EOS Mythos Vapor | Links + rechts, je 2 kW crna | 4,0 kW | 946265 | |
| EOS Mythos Vapor | Links, 3 kW bela | 3,0 kW | 945900 | |
| EOS Mythos Vapor | Rechts, 3 kW bela | 3,0 kW | 945904 | |
| EOS Mythos Vapor | Links + rechts, je 3 kW bela | 6,0 kW | 946256 | |
| EOS Mythos Vapor | Links, 2 kW bela | 2,0 kW | 945899 | |
| EOS Mythos Vapor | Rechts, 2 kW bela | 2,0 kW | 945903 | |
| EOS Mythos Vapor | Links + rechts, je 2 kW bela | 4,0 kW | 946259 | |
| EOS Mythos Vapor | Links, 3 kW Water Reflection | 3,0 kW | 949595 | |
| EOS Mythos Vapor | Rechts, 3 kW Water Reflection | 3,0 kW | 949596 | |
| EOS Mythos Vapor | Links + rechts, je 3 kW Water Reflection | 6,0 kW | 949602 | |
| EOS Mythos Vapor | Links, 2 kW Water Reflection | 2,0 kW | 949593 | |
| EOS Mythos Vapor | Rechts, 2 kW Water Reflection | 2,0 kW | 949594 | |
| EOS Mythos Vapor | Links + rechts, je 2 kW Water Reflection | 4,0 kW | 949599 | |
| EOS Mythos Vapor | Links, 3 kW dark bronze | 3,0 kW | 949404 | |
| EOS Mythos Vapor | Rechts, 3 kW dark bronze | 3,0 kW | 949405 | |
| EOS Mythos Vapor | Links + rechts, je 3 kW dark bronze | 6,0 kW | 949415 | |
| EOS Mythos Vapor | Links, 2 kW dark bronze | 2,0 kW | 949402 | |
| EOS Mythos Vapor | Rechts, 2 kW dark bronze | 2,0 kW | 949403 | |
| EOS Mythos Vapor | Links + rechts, je 2 kW dark bronze | 4,0 kW | 949412 |
