Professional · Sauna heaters
EOS Mega HD series
According to EOS, the most powerful electric sauna heater in the world.
- Power
- 36–72 kW
Power
Model
Delivery with certification and an approved project. Heaters from the Design and Professional lines are supplied with certification and submission of the project, so that we can approve delivery and installation. Classic and Standard heaters can be ordered by anyone.
Send project for approval
We send the price, availability and delivery time in reply to your enquiry, usually the same or the next working day.
Data is being transferred from the EOS catalogue.
For technical data and documents, see the original page or send us an enquiry.
| Electrical connection | 400 V 3N ~ 50/60 Hz |
|---|---|
| Fuse Controller | 1 x 16 A |
| Device dimensions H/W/D (cm) | 100 / 120 / 80 (Mega HD) 100 / 90 / 80 (Mega S HD) |
| Stone quantity | Oko 150 kg (Mega HD) oko 100 kg (Mega S HD) |
| Power module required (36 / 42-54 / 60-72 kW) | PEB 36 / 1x PEB 18 + 1x PEB 36 / 2 x PEB 36 |
| Power | For cabin volume / Minimum ventilation openings / Weight without stones and packaging (Mega / Mega S) |
| 36,0 kW | 60 - 75 m³ / 50 x 10 cm / - / 110 kg |
| 42,0 kW | 65 - 80 m³ / 50 x 12 cm / 112 kg / 111 kg |
| 48,0 kW | 70 - 90 m³ / 60 x 12 cm / 114 kg / 112 kg |
| 54,0 kW | 80 - 100 m³ / 70 x 12 cm / 116 kg / - |
| 60,0 kW | 100 - 130 m³ / 70 x 12 cm / 118 kg / - |
| 72,0 kW | 130 - 160 m³ / 80 x 12 cm / 120 kg / - |
| Model | Version | Power | EOS item no. | |
|---|---|---|---|---|
| EOS Mega HD | 42,0 kW | 947735 | ||
| EOS Mega HD | 48,0 kW | 947736 | ||
| EOS Mega HD | 54,0 kW | 947737 | ||
| EOS Mega HD | 60,0 kW | 947738 | ||
| EOS Mega HD | 72,0 kW | 947739 | ||
| EOS Mega S HD | 36,0 kW | 948094 | ||
| EOS Mega S HD | 42,0 kW | 948045 | ||
| EOS Mega S HD | 48,0 kW | 948044 |
According to the EOS spare parts list 2026. Prices and delivery times on request.
| Part | For heater power | Qty | EOS item no. | |
|---|---|---|---|---|
| Heating elements – Mega S HD | ||||
| Heating element 3000 W | 36,0 kW | 12 | 2000 7176 | |
| Heating element 3000 W | 42,0 kW | 14 | 2000 7176 | |
| Heating element 3000 W | 48,0 kW | 16 | 2000 7176 | |
| Heating elements – Mega | ||||
| Heating element 3000 W | 42,0 kW | 14 | 2001 2967 | |
| Heating element 3000 W | 48,0 kW | 16 | 2001 2967 | |
| Heating element 3000 W | 54,0 kW | 18 | 2001 2967 | |
| Heating element 3000 W | 60,0 kW | 20 | 2001 2967 | |
| Heating element 3000 W | 72,0 kW | 24 | 2001 2967 | |
| Heating elements – Mega HD | ||||
| Heating element 3000 W | 42,0 kW | 14 | 2000 7176 | |
| Heating element 3000 W | 48,0 kW | 16 | 2000 7176 | |
| Heating element 3000 W | 54,0 kW | 18 | 2000 7176 | |
| Heating element 3000 W | 60,0 kW | 20 | 2000 7176 | |
| Heating element 3000 W | 72,0 kW | 24 | 2000 7176 | |
| Other parts | ||||
| Stone basket Mega | 94 9638 | |||
| Stone basket Mega S | 94 9639 | |||
