Standard · Control units
EOS Econ 1 Serie
Model
We send the price, availability and delivery time in reply to your enquiry, usually the same or the next working day.
Data is being transferred from the EOS catalogue.
For technical data and documents, see the original page or send us an enquiry.
| Electrical connection | 400 V 3N ~ 50 Hz |
|---|---|
| SchaltSnaga | Max. 9 kW ohmsche Last (AC1 - Betrieb) humid mode: 6 kW + 3 kW for Verdampfereinrichtung (H1) |
| Connection option for LSG | ne |
| Temperature control range | 30 - 115 °C Finnisch (D1/H1) 30 - 70 °C Combi (H1) |
| Humidity control | Zeitproportional, 10 Schritte |
| Outputs | Light (100 W), Fan (100 W) |
| Heating time limit | 6 h |
| Dimensions H/W/D in cm | 22 / 25 / 6,7 |
| Umgebungstemperaturen beim Betrieb | -10 do +40 °C |
| Težina without packaging approx. | 1,0 kg |
| Model | Version | Power | EOS item no. | |
|---|---|---|---|---|
| EOS Econ D1 | 946136 | |||
| EOS Econ H1 | 946137 |
